The Schiller Cardiovit AT-10 plus Stress System combines resting ECG, exercise ECG, pacemaker measurement, HRV analysis, signal-averaged ECG analysis, thrombolysis software and spirometry in a single system like its legendary predecessor, the CARDIOVIT AT-10.

PDF: AT-10 Plus Eng

• Resting ECG
• Exercise ECG (ergometry)
• Pacemaker measurement
• Heart rate variability (HRV)
• Signal-averaged ECG analysis (SAECG)
• Thrombolysis software
• Vectorcardiography (combined with SEMA)
• Serial ECG comparison (combined with SEMA)
• Complete spirometry tests
All this at the touch of a button – and even networkable!

Schiller Cardiovit AT-10 plus Stress System Performance:
• 12-/16-channel resting and exercise ECG
• High-resolution 10.4“ TFT color screen
• Built-in thermal printer with A4 printing paper
• Easy operation
• Optimum integrability with data management systems
• Comprehensive network functions (Ethernet and WLAN)
• Modem
• Optional barcode scanner
• Internal memory for up to 350 ECG recordings
• Complete integration with the SEMA-200 cardiology data management system
• Data export and archiving in XML format
• Extendable to a complete ergometry and spirometry station

The Schiller Cardiovit AT-10 Plus ECG Monitor is a high-value performance, multi-purpose and uniquely designed 12-Channel Resting & Exercising ECG Monitoring device made to record & print-out electrical activities of the heart, using electrodes, over a period of time and, with a built-in spirometer, measure the air capacity of the lungs. It is an awesome choice for hospitals, medical facilities and private practices who specialize in EKG Procedures.

Functional and Unique. Built with a laptop-like design, the Cardiovit AT-10 Plus ECG Monitor features a 10.4″ TFT Color LCD tilt-screen, an 8.5″ x 11″ full-size thermal printer and a built-in LAN & VGA Output ports. The System can be used wherever ECG and Spirometry Data must be obtained. Direct key functions and the on-screen menus allow the user to have a quick, hassle-free and dependable operation.

Great Software. With the included software, the AT-10 Plus ECG Monitor has all the included requirements of an integrated diagnostic workstation. It features resting & exercise ECG recording, pacemaker detection, HRV (Heart Rate Variability) analysis and spirometry tests. The AT-10 Plus comes with Pre-programmed settings that are easily activated. Preferred Settings can be configured and stored by the users at a press of a key. Because of this, learning and operation become fast and easy.

Data Management: The AT-10 Plus can hold up to 350 ECG Recordings and because of the built-in LAN ports, can easily be integrated with existing hospital information systems (HIS) for optimal workflow. The Patient’s Data and recordings can be transferred with an XML format. Also, to save paper, you can first transmit the 5-minute full disclosure view recording Schiller SEMA-200 data management system on the PC for final editing or printout.

The Schiller Cardiovit AT-10 Plus ECG Monitor with Spirometer comes with a 3 Year Limited Warranty.
